Aavara HDMI Over Coax Receiver

The Aavara HDMI Over Single Coax Extender with IR Remote Command Pass-Thru delivers ultra-high-quality 1080p video transmission up to 120 metres over a single RG6U coaxial cable. Ideal for simplified installations, it supports multi-layer cascading for multiple displays and remote control of video source devices.

Key Features

• Broadcast-grade coaxial transmission with IR remote command pass-thru for remote control of video source devices
• Supports 1080p video resolution up to 120 metres via single RG6U coax cable, suitable for indoor and outdoor use
• Sender unit includes built-in 1 to 2 coaxial splitter, allowing connection to two receivers
• Receiver features one coaxial cascade output for multi-layer cascading, supporting up to 5 layers and 10 or more connected TVs, displays, or projectors
• Includes F to BNC adapters for coaxial cables with F connectors
• BNC connectors ensure solid, vibration- and shock-resistant coaxial cable connections
• HDMI version 1.3b and HDCP compliant
• Hassle-free plug-and-play installation
• Compatible with Aavara PCE122 series

Specifications

• HDMI Specification: 1.3b Compliant
• HDCP Specification: 1.2 Compliant
• Input Connector (Sender): COAX BNC x 2 (1 to 2 splitter)
• Output Connector (Receiver): HDMI Type A x 1, COAX BNC x 1 (Cascade Out)
• Video Bandwidth: 2.97 Gb/s data rate
• HD Input Resolution: 720p, 1080i, 1080p
• PC DVI Input Resolution: 1280x720, 1920x1080 @ 50/60 Hz standard timing
• Output Resolution: 720p, 1080i, 1080p
• Maximum Distance: 120 metres using high-quality dual or quad shielded RG6U coaxial cable with 3 GHz certification
• Dimensions: 92.4 x 117.8 x 29 mm
• Weight: 249 g
• Operating Temperature: 0ºC to 40ºC (32ºF to 104ºF)
• Operating Humidity: 10% to 85% (non-condensing)
• Storage Temperature: -20ºC to 60ºC (-4ºF to 140ºF)
• External Power Supply: 5V DC / 2A
• Power Consumption: 5 Watts (max)

What's in the Box

• HDMI Over Single Coax Sender & Receiver
• 5V DC Adapter
• IR Jack
• User Manual
• F to BNC Adapters (2 pcs)
