Aavara HDMI Over IP Receiver

The Aavara PB5000 HDMI Over IP Receiver delivers stunning Ultra High Definition 1080p video distribution over IP networks, ideal for digital out-of-home (DOOH) and signage deployments. Experience smooth, vivid full-motion video with CD-quality audio, crystal-clear images, and sharp text for maximum visual impact and easy readability.

Key Features

• 1080p Ultra High Quality video transmission with up to 16 groups multi-casting
• Flexible and scalable HDMI 1080p broadcasting over Gigabit Ethernet LAN
• Supports 1-to-1, 1-to-many, and multi-casting architectures without increasing LAN bandwidth load
• Multi-casting groups supported via managed Gigabit Ethernet switches with 802.1Q VLAN and IGMP functions (up to 16 groups)
• 16 sets of Class C IP dip switch configuration on both sender and receiver for easy multi-casting group matching
• IR Pass-Thru support in 1-to-1 extender configuration for remote control of source devices
• Easy video channel matching technology enables multi-casting with low-cost unmanaged Gigabit switches
• Plug and play setup with simple dip switch adjustments—no complex network configuration required

Specifications

• HDMI Specification: 1.3 Compatible
• DVI Specification: 1.0 Compliant
• HDCP Specification: 1.1 / 1.2 Compliant
• Sender Connectors: Power adapter input, RJ45, IR emitter connector, HDMI
• Receiver Connectors: Power adapter input, RJ45, HDMI
• Receiver HDMI Audio Output: Stereo L/R, 16-bit, 48kHz
• Supported HDMI Video Resolutions: 480i/p, 576i/p, 720p, 1080i/p
• Supported HDMI PC Resolution: Up to 1920x1200 @ 60Hz
• Extender Mode CAT5e Cable Length: 100m
• Extender Mode: Direct sender to receiver connection via CAT5e/6/7 cable
• Broadcaster Mode: Sender to multiple receivers via LAN (Local Area Network)
• Broadcaster Mode Length: Unlimited within LAN
• IR Control Pass-Thru: Infrared remote control of source equipment from receiver side (works only with first powered-on PB5000 receiver in 1-to-many mode)
• Operating Temperature: 0–40ºC
• Storage Temperature: -20–50ºC
• Humidity Range: 5%–90% RH
• Power Consumption: 5W
• Power Adapter: DC 5V/2A
• Material: Metal
• Dimensions: 165 x 116 x 28 mm
• Product Weight: 325g
• Optional Accessory: Mounting Kit (MK-100)

What's in the Box

• 1080p HDMI Broadcaster Sender & Receiver
• 5V DC Adapter
• User Manual
• IR Emitter Cable
