Aeotec Nano SwitchZ-Wave Plus SmartSwitch

Aeotec Nano Switch - Z-Wave Plus Smart Switch

The Aeotec Nano Switch is a compact, wireless smart switch that installs invisibly behind your existing wall switches or power sockets, enabling full remote control, automation, and energy monitoring via Z-Wave Plus technology.

Key Features

• Compact design fits behind existing switches and sockets
• Wireless control and scheduling from anywhere
• Compatible with standard light switches and power outlets
• Optional energy metering with 99% accuracy
• Supports up to 15 amps per channel (Dual Nano Switch supports 10 amps per channel)
• Secure AES-128 bit wireless encryption
• Firmware updates via Z-Wave Plus wireless technology
• 67% greater wireless range with +2.5dBm signal strength
• Compatible with Z-Wave gateways and devices including WallMote and WallSwipe
• Requires neutral wire for safe installation
• DIN rail compatible with generic housing
• Supports control of 24VDC low voltage devices

Overview

The Nano Switch transforms your home by enabling wireless control of your existing light switches and power sockets without replacing them. Simply install the Nano Switch behind your current switch or socket, and gain full control, automation, and scheduling capabilities through your Z-Wave gateway or app.

Ideal for controlling non-dimmable lights and appliances, the Nano Switch supports intelligent automation, remote access, and energy monitoring to help reduce power consumption. For double gang outlets or switches, the Dual Nano Switch offers control and monitoring for two channels, each supporting up to 5 amps / 1150 watts.

Note that the Nano Switch requires a neutral wire and does not support dimming. For dimmable lighting, consider Aeotec’s Nano Dimmer.

Specifications

• Dimensions: 4.2cm x 4cm x 2.5cm (1.65” x 1.6” x 0.98”)
• Depth: 19.5mm / 0.77” (60% smaller than original Micro Smart Switch)
• Power control: up to 15 amps (Dual Nano Switch up to 10 amps per channel)
• Wireless range: up to 150 metres / 492 feet
• Wireless encryption: AES-128 bit
• Compatibility: Z-Wave Plus (Gen5), standard indoor/outdoor bulbs, power sockets, switches
• Energy metering: Optional version with 99% accuracy available
• Voltage support: High voltage and 24VDC low voltage devices

What's in the Box

The product listing does not specify box contents.

Installation and Safety

The Nano Switch is designed for easy installation behind existing switches or sockets, fitting even the smallest junction boxes. It requires a neutral wire for safe operation and includes built-in surge protection. Wiring supports thicker wires (up to 25% thicker than previous models) for safer and easier installation.

Images

For energy metering version, see Aeotec Nano Switch Power Monitoring.
