Barco ClickShareCX-50 Gen2 EU Setincluding

Barco ClickShare CX-50 2nd generation is a premium wireless conferencing system for high-impact meeting rooms and boardrooms, with dual-screen people/content layouts, UC or BYOD workflows, and a wired room dock for 4K sharing.

Key Features

• Dual screen: people and content side by side on two displays
• Effortless switching between UC mode and BYOD experience
• Wired room dock for 4K content sharing and alternative connectivity
• Video outputs up to 3840×2160 @ 60 Hz (HDMI 2.1 / USB-C DisplayPort Alt Mode)
• Native AirPlay, Google Cast and Miracast; ClickShare Buttons (2) and ClickShare App (desktop & mobile)
• Wireless conferencing via App or Button; touch screen support and interactivity
• Cloud-managed; ANSSI CSPN security certified (per Barco spec sheet)

Overview

When you enter the room, ClickShare CX-50 Gen2 can connect you to room devices such as cameras, mics, speakers, sound bars and displays. Start a meeting from a laptop with the ClickShare Button or App on your preferred video conferencing platform.

Specifications

Figures below are from the official Barco ClickShare CX-50 2nd generation Spec Sheet (assets.barco.com; last updated 24 Jul 2026).

General and video / audio I/O

Source: Barco ClickShare CX-50 2nd generation Spec Sheet - General Specifications.

Operating system (clients)	Windows 10 or higher; macOS 11 (Big Sur) and higher; Android v11 and higher (ClickShare App); iOS 14 and higher (ClickShare App)
Video outputs	HDMI: 3840×2160 @ 60 Hz, HDMI 2.1 Source; USB-C: 3840×2160 @ 60 Hz, DisplayPort Alternate Mode Source with DisplayPort v1.2
Video inputs	USB-C: 3840×2160 @ 30 Hz, DisplayPort Alternate Mode Sink with DisplayPort v1.2
Audio output	USB, jack, HDMI
ClickShare Buttons	2
ClickShare App	Desktop & Mobile
Native protocols	AirPlay, Google Cast, Miracast
Maximum sources simultaneously on screen	2
Noise level	Max. 25 dBA @ 0-30 °C; Max. 30 dBA @ 30-40 °C

Network, wireless and security

Source: same Spec Sheet.

Wired authentication	802.1X, EAP-TLS, EAP-TTLS, PEAP
SoftAP client mode	802.1X EAP-TLS, EAP-TTLS, PEAP, and WPA2 PSK
Authentication protocol	WPA2-PSK in stand-alone mode; WPA2-PSK or IEEE 802.1X using the ClickShare Button in network integration mode
Wireless transmission protocol	IEEE 802.11 a/g/n/ac and IEEE 802.15.1
Reach	Max. 30 m (100 ft) between ClickShare Button and Base Unit
Frequency band	2.4 GHz and 5 GHz (DFS channels supported in select countries)
Connections	1× Ethernet LAN 1 Gbit; 1× USB-C 2.0 (back); 2× USB-A 2.0 (back); 1× USB-A 2.0 (front); analogue line out on 3.5 mm mini-jack; digital S/PDIF
Network connection	LAN & WiFi (dual)
Wireless conferencing	Via App or Button
Touch screen support & interactivity	Yes

Environmental, power and physical

Source: same Spec Sheet.

Temperature range (operating)	0 °C to +40 °C; Max. 35 °C at 3000 m
Temperature range (storage)	−20 °C to +60 °C
Humidity	Storage: 0 to 90% RH non-condensing; Operation: 0 to 85% RH non-condensing
Anti-theft system	Kensington lock
Certifications	FCC/CE
Management and reporting	Yes
Warranty (manufacturer statement)	1 year standard; 5 years coverage upon registering via SmartCare
Dimensions (H × W × D)	39 × 200 × 202 mm
Power consumption	Operational: 50 W (max)
Power supply	Standard 110/220 V AC plug
Weight	900 g

Datasheets

Public manufacturer documents (link only - this does not add a downloads module):

• Barco ClickShare CX-50 2nd generation Spec Sheet (PDF)
• Barco ClickShare CX-50 Gen2 product page
