Bose FreeSpaceDS16SE WallMounted

The Bose FreeSpace DS16SE is a premium wall-mounted loudspeaker designed for clear background music and speech reproduction in various installed applications. It features a broad 170° x 160° coverage pattern and a frequency range extending down to 80 Hz, delivering consistent, high-quality sound.

Key Features

• Full-range loudspeaker with a single 2.25" (57 mm) full-range driver in a ported enclosure, ideal for surface mounting in background music and paging applications.
• Simple 1->2->3 installation system with mounting hardware allowing horizontal and vertical orientation, including adjustable pitch and yaw.
• Integrated multi-tap transformer featuring an innovative thumb wheel adjustment for easy tap setting changes from under the front end cap.
• Shared voicing across the entire FreeSpace DS product family, enabling DS 16, DS 40, and DS 100 loudspeakers to integrate seamlessly with consistent tonal quality.
• Compatible with FreeSpace 3 Acoustimass® modules (surface or flush-mount) for extended bass response.
• Supported by a suite of accessories, including wall-mount bracket, ceiling-mount bracket, pole-mount bracket, and junction boxes.

Specifications

Enclosure: PC/ABS (white), polypropylene (black); textured finish.

Environmental: DS 16S for indoor use only; DS 16SE rated for outdoor use per IEC 529 IP55.

Connectors: Three-terminal barrier strip integrated on included mounting bracket. Optional accessories available for ceramic connector and thermal fuse. Wire gauge: 18 AWG (0.8 mm) to 14 AWG (2.0 mm).

Suspension / Mounting: Included bracket allows horizontal or vertical mounting with pitch or yaw adjustment. Rear enclosure hole sized for #8 or M4 self-tapping screw for safety chain.

Dimensions (Enclosure only): 124 mm H x 250 mm W x 117 mm D (4.9" x 9.9" x 4.6"). Depth with wall mount bracket: 161 mm (6.4").

Net Weight: 1.8 kg (4.0 lb).

Colour: Black, White, Paintable.

Frequency Response (+/-3 dB): 95 Hz - 17 kHz

Frequency Range (-10 dB): 80 Hz - 19 kHz

Nominal Dispersion: 170° horizontal x 160° vertical

Long-Term Power Handling: 16 W (64 W peak)

Sensitivity (SPL / 1 W @ 1 m): 84 dB SPL

Maximum SPL @ 1 m: 96 dB SPL (102 dB SPL peak)

Nominal Impedance: 8 Ω (transformer bypassed)

What's in the Box

• 1 x Bose FreeSpace DS16SE loudspeaker
• 1 x Mounting bracket
