Club3D USB 3.1Gen1 4K DockingStation

Club3D CSV-3103D — USB 3.1 Gen1 docking station with dual monitor support up to 4K, Gigabit Ethernet, and USB hub, powered by the DisplayLink DL-5900 chipset.

The CSV-3103D connects to a laptop via USB 3.1 Gen1 and instantly expands connectivity with DisplayPort and HDMI display outputs, three USB 3.1 Gen1 ports, Gigabit Ethernet, and 3.5mm audio. Single-display mode supports up to 3840×2160@30Hz; dual-display mode supports up to 2× 1920×1200@60Hz. BC1.2 fast charging is available on the downstream USB ports.

Key features

• Dual monitor: DisplayPort + HDMI via DisplayLink DL-5900
• Single display: up to 4K (3840×2160) @30Hz
• Dual display: up to 2× 1920×1200 @60Hz
• 3× USB 3.1 Gen1 downstream ports
• BC1.2 fast charging
• Gigabit Ethernet
• 3.5mm stereo audio + microphone

Specifications

• Model: CSV-3103D
• Host connection: USB 3.1 Gen1
• Display outputs: DisplayPort + HDMI
• Max resolution: 4K@30Hz (single) / 1920×1200@60Hz (dual)
• USB ports: 3× USB 3.1 Gen1
• Network: Gigabit Ethernet
• Chipset: DisplayLink DL-5900
