( 06 / 06 )Lab.gruppenIPX-4800 4800WInstallation
Lab.gruppen IPX-4800 — 4800 W professional installation amplifier from the IPX series, with Class D IDEEA technology, comprehensive DSP, Dante audio networking, and full protection circuits for high-power commercial and installation applications.
The IPX-4800 delivers high output power with Lab.gruppen's IDEEA Class D topology, maintaining efficiency and low heat output during extended operation in always-on installation environments such as concert halls, theatres, and conference centres. Built-in DSP provides input EQ, crossover, delay, and limiter settings configurable from the front panel or via dedicated software. Dante networking simplifies multi-amplifier integration over standard Ethernet cabling, reducing infrastructure complexity in large installations. AES3 digital and analogue inputs provide flexible source connectivity. Comprehensive short circuit, thermal overload, and DC protection circuits ensure safe continuous operation under demanding conditions.
4800 W Class D professional amplifier (IDEEA)
Built-in DSP: EQ, crossover, delay, limiter
Dante digital audio networking over Ethernet
( Specifications )
| Frequency response | 20 Hz - 20 kHz |
| Input Impedance | 20 kOhms |
| Amplifier Technology | Class D |
| Brand | Lab Gruppen |
| Bridge Mode | Yes |
| Color | Black |
| Compliance | CE, FCC, RoHS |
| Cooling | Regulated fans |
| Crosstalk | <-70 dB |
| Damping Factor | >5000 |
| Depth | 377 mm |
| Display | Front panel LCD |
| DSP Features | Crossover, EQ, Delay, Dynamics Processing |
| Ethernet Control | Yes |
