Lumi LCD-CM344Folding CeilingMount

Lumi LCD-CM344 Folding Ceiling Mount TV Bracket

The Lumi LCD-CM344 is an economical folding ceiling mount designed for 23” to 55” TVs, supporting up to 20kg (44lbs). Its fold-up locking design saves space and offers versatile installation options, including below cabinets, work areas, pitched ceilings, and home setups.

Key Features

• Folding Design: Saves space by keeping the screen and arm out of the way when not in use.
• 360° Swivel Ability: Allows multiple viewing angles for optimal screen positioning.
• Adjustable Vertical Rail: Easily adjust the TV to your preferred height.
• Lightweight and Durable: Constructed from aluminium and steel for strength and longevity.
• Compatible with Curved TVs: Supports both flat and curved screens.
• VESA Compatible: Supports multiple VESA mounting patterns up to 400x400mm.

Specifications

Product Category:	TV Ceiling Mount
Rank:	Standard
Material:	Steel
Metal Sheet Thickness:	VESA Panel THK=1.5mm cold-rolled sheet, Wall Plate THK=2mm cold-rolled sheet (0.059" and 0.079" respectively)
Pipe Size:	30x20x1.5mm Square Steel Tube (1.2"x0.79"x0.059")
Surface Finish:	Powder Coating
Colour:	Fine Texture Black
Dimensions:	614x435x165mm (24.2"x17.1"x6.5")
Fit Screen Size:	23" - 55"
Fit Curved TV:	Yes
Mounting Hole Pattern:	VESA Only
VESA Compatible:	75x75, 100x100, 100x200, 200x100, 200x200, 200x300, 300x200, 200x400, 400x200, 300x300, 300x400, 400x300, 400x400
Max. Mounting Hole:	400x400mm
Weight Capacity:	20kg (44lbs)
Strength Tested:	3 Times Approved
Profile:	83mm (3.3")
Tilt Range:	0° to -80°
Swivel Range:	+45° to -45°
TV Height Range:	Min 520mm to Max 614mm (20.5" to 24.2")
Installation:	Ceiling Mounted
Panel Type:	Detachable Panel
Wall Plate Type:	Fixed Wall Plate
Direction Indicator:	Yes
Cable Management:	No
Bubble Level:	No
Accessory Kit Package:	Normal/Ziplock Polybag, Compartment Polybag
