Mission ZX 2 - Bookshelf Loudspeakers (Pair)
The Mission ZX 2 bookshelf loudspeakers deliver superior sound quality with advanced audio technology and refined design, perfect for premium electronics and stylish South African homes. Engineered with Mission's philosophy, ‘Music leads, Technology follows’, these speakers provide a dynamic, detailed listening experience.
Key Features
- 2-way bookshelf speaker with bass reflex enclosure
- 5.25" (130mm) aluminium cone bass driver for clear, dynamic bass
- 1.5" (38mm) ring dome treble unit with extended high-frequency response up to 30kHz
- Advanced DiaDrive bass/midrange unit with vented aluminium matrix cone
- New driver bracing system for improved mechanical integrity and transient response
- Inverted Driver Geometry (IDG) for seamless acoustic integration
- Recommended amplifier power: 25-150W
- Nominal impedance: 8 ohms compatible
- Available in gloss black and gloss white finishes with premium trims
Specifications
| General Description | 2-way bookshelf speaker |
|---|---|
| Enclosure Type | Bass reflex |
| Transducer Complement | 2-way |
| Bass Driver | 5.25" (130mm) aluminium cone |
| Treble Driver | 1.5" (38mm) ring dome |
| AV Shield | No |
| Sensitivity (2.0V @ 1m) | 89dB |
| Recommended Amplifier Power | 25-150W |
| Peak SPL | 110dB |
| Nominal Impedance | 8 ohms compatible |
| Minimum Impedance | 3.8 ohms |
| Frequency Response (+/-3dB) | 45Hz – 24kHz |
| Bass Extension (-6dB) | 40Hz |
| Crossover Frequency | 2.4kHz |
| Dimensions (HxWxD) | 420 x 240 x (350+12) mm |
| Net Weight | 9.4kg per speaker |
Technology Highlights
Ring Dome Treble Unit: The innovative ring dome design fixes the centre of the dome and positions the voice coil across it, driving the treble unit more accurately and efficiently. This reduces distortion and extends frequency response beyond 30kHz, enhancing transient performance and musical detail.
DiaDrive Bass/Midrange Unit: Features an advanced aluminium matrix cone with venting to reduce resonance and improve midrange clarity beyond 3kHz. The vented driver surround and serrated slot port design minimise distortion and chuffing noise for cleaner bass output.
Driver Bracing System: Oversized magnet systems and specialised bracing improve mechanical integrity, delivering dynamic bass with superior detail and extension.
Inverted Driver Geometry (IDG): This design equalises acoustic path lengths between bass/midrange and treble units, ensuring seamless integration for a unified soundstage.
Design & Finish
The Mission ZX 2 speakers are available in gloss black and gloss white finishes with carefully selected trims and driver materials that complement their advanced technology and luxurious appearance.
