MuxLab MonoPro™ XLR Male to Cat Balun (Model 500025)

The MuxLab MonoPro™ XLR balun (model 500025 - male connector) enables the extension of standard AES analog or digital XLR audio channels over a single Cat5e/6 cable, ideal for professional audio environments such as rental, staging, and live sound.

Key Features

• Extends line level audio signals up to 5,000 ft (1.5 km) via single Cat5e/6 cable
• Supports digital audio signals up to 1,400 ft (426 m)
• Impedance: output 600 Ω / input 600–20k Ω (analog audio); 110 Ω (digital audio)
• Sample rate support up to 96 kHz
• Cat5e/6 cable terminates inside the balun for secure connection
• Locking metal XLR3 male connector with heavy-duty cable strain relief
• Optional terminal for ground/shield connection
• Supports active microphones (requires ground pin connected at both ends)

Specifications

• Dimensions: 47 mm x 25 mm diameter (1.875" x 1") plus 127 mm (5") XLR3 lead
• Weight: 75 g (2.64 oz)
• Connector type: XLR3 male (model 500025); female counterpart is model 500026
• Warranty: MuxLab Limited Lifetime Warranty (see website for details)

Ordering Information

Model 500025 features an XLR3 male connector and is sold individually (used in pairs with model 500026, which has an XLR3 female connector).
