( 01 / 01 )Optoma ZX300 4KCompatible LaserProjector
Optoma ZX300 - 4K Compatible Laser Projector
The Optoma ZX300 is a high-brightness, 4K compatible laser projector designed for professional installations. Featuring Optoma DURACORE technology and IP6X dust resistance, it delivers vibrant colours, outstanding reliability, and up to 20,000 hours of low-maintenance operation, making it ideal for commercial and performance environments.
Key Features
- High brightness: 3,500 ANSI lumens with constant brightness for up to 5 years or 12,000 hours
- 4K and HDR compatible: Accepts native 4K signals and supports HDR10 for enhanced contrast and colour depth
- Optoma DURACORE technology: Airtight optical engine with IP6X dust resistance for long-lasting reliability
- Long laser light source life: Up to 20,000 hours with virtually zero maintenance
- Flexible installation: 360° and portrait mode projection capability with tilt-free orientation
- Low noise operation: Only 28dB in ECO mode for quiet environments
- Quick start-up and shutdown: Minimal cool-down time and energy-saving pause projection feature
- Vibrant colours: Exceeds HDTV Rec. 709 standards for accurate and lifelike images
- 24/7 operation: Built with industry-proven components for continuous use
Overview
Designed for businesses, conference rooms, higher education, auditoriums, exhibitions, entertainment venues, and simulation, the Optoma ZX300 offers excellent value for entry-level professional installations. Its compact design, high brightness, and stunning image quality create larger-than-life experiences with minimal maintenance.
Specifications
| Display Technology | DLP |
|---|---|
| Native Resolution | XGA 1024 x 768 |
| Brightness | 3500 ANSI Lumens |
| Contrast | 300,000:1 (with Extreme Black) |
| Light Source | Laser phosphor |
| Light Source Life | 20,000 hours to 50% brightness (Eco mode) |
| Throw Ratio | 1.94 – 2.16 |
| Zoom Type | 1.1x Manual |
| I/O Connectors | HDMI x2, VGA-in, USB-A (5V/1.5A), Micro USB, Audio in, Audio out, RS-232 |
| Speaker (Watts) | 15W |
| Keystone Correction | ±40° Vertical |
| Weight (Kg) | 4 |
| Dimensions (W x D x H) (mm) | 337 x 265 x 108 (excluding adjustment feet) |
| Aspect Ratio | 4:3, 16:9 or 16:10, LBX, Native, Auto |
| Projection Screen Size | 39.37” – 464.57” |
| Projection Distance | 1.0 – 11.8m |
| Uniformity | 75% |
| Computer Compatibility | WUXGA, 1080P, UXGA, SXGA+, SXGA, WXGA+, WXGA, 720P, XGA, SVGA, VGA |
| Video Compatibility | 480i/p, 576i/p, 720p/1080i (50/60Hz), 1080p (50/60Hz), NTSC, PAL, SECAM |
| 3D Support | Full 3D |
| Horizontal Scan Rate | 15.375 – 91.146 kHz |
| Vertical Scan Rate | 50 – 85 Hz |
| Displayable Colours | 1073.4 million colours (10 bit) |
| Noise Level | 28dB (Eco mode) |
| Power Supply | 100–240V, 50–60Hz, auto-switching |
| Power Consumption | 145W Bright mode (< 0.5W Standby) |
| 360° Operation | Yes |
| Portrait Mode | Yes |
| Projection Method | 360° operation, Portrait mode supported |
Additional Information
The ZX300 maintains constant 3,500 lumens brightness for up to 5 years or 12,000 hours when brightness is set below 100%, ensuring stable performance over time. Its mercury-free laser light source and airtight optical engine provide a low total cost of ownership with minimal maintenance.
With tilt-free orientation, the projector supports full 360° vertical axis projection including ceiling and floor installations, as well as portrait mode for digital signage or narrow projection areas.
Enjoy quick start-up and shutdown with rapid full brightness and a pause projection feature that completely turns off the light source to save energy. The projector operates quietly at only 28dB in ECO mode, making it suitable for noise-sensitive environments.
