WyreStorm 4K UHD 1x2 HDMI Splitter - Reliable 4K Content Distribution

The WyreStorm Express 1:2 4K HDMI Splitter enables lossless duplication and distribution of a single HDMI 4K or HD source to two connected displays. It supports resolutions up to 4Kx2K, providing a simple, flexible, and reliable solution for replicating content across multiple devices.

Key Features

• 1 HDMI input to 2 simultaneous HDMI outputs
• Supports 4K UHD and DCI standards at 4:4:4 30Hz
• Plug-and-play connectivity with automatic EDID and HDCP negotiation
• Low profile 18mm (0.7 inch) slim chassis for easy installation
• Supports 4K resolutions up to 4096x2160@30Hz and HD up to 1080p@60Hz
• Transmission distances up to 10m (33ft) for 4K/1080p input and 4K output; 15m (49ft) for 1080p output using standard HDMI cables
• Multichannel HD audio support, mirroring the source
• Full 3D support including frame packing, sequential, and stereoscopic
• Threaded power port for locking or standard 5V DC connection
• Front panel LED indicators for input/output and power status
• Compliant with HDCP 1.4 and anti-piracy protocols for legal content distribution
• Units are cascadable: up to 12 times for 1080p and 3 times for UHD 4K
• Compatible with WyreStorm EXP-SCL-DAC-4K scaler with Dolby downmixer (sold separately) for scalable combined 4K/HD distributions

Specifications

Audio and Video

• Inputs: 1x HDMI In 19-pin HDMI Type A female
• Outputs: 2x HDMI Out 19-pin HDMI Type A female
• Audio Formats: 2ch PCM; Multichannel up to Dolby TrueHD and DTS-HD Master Audio
• Max Video Resolution:
  • 1920x1080p @60Hz 12bit (15m/49ft)
  • 3840x2160p @30Hz 4:2:0 8bit (7m/23ft)
  • 4096x2160p @30Hz 4:2:0 8bit (7m/23ft)
• Color Depth: 1080p - 12bit; 4K - 8bit
• Maximum Pixel Clock: 340MHz

Communication and Control

• HDMI Version: HDMI 1.4b with HDCP 1.4 support

Power

• Power Supply: 5V DC 1A
• Max Power Consumption: 1.7W

Environmental

• Operating Temperature: 0°C to 45°C (32°F to 113°F)
• Operating Humidity: 10% to 90%, non-condensing
• Storage Temperature: -20°C to 70°C (-4°F to 158°F)
• Storage Humidity: 10% to 90%, non-condensing
• Maximum BTU: 5.8 BTU/hr

Dimensions & Weight

• Rack Units/Wall Box: <1U
• Height: 18mm (0.71in)
• Width: 140mm (5.52in)
• Depth: 65mm (2.56in)
• Weight: 0.26kg (0.57lbs)

Regulatory

• Safety and Emission: CE, FCC, RoHS compliant

Design and Compliance

The WyreStorm Express 1:2 HDMI Splitter features a slim, low-profile chassis for discreet installation under desks or tables without compromising durability. It is fully compliant with HDCP anti-piracy protocols, ensuring legal and trouble-free content distribution.

What's in the Box

• WyreStorm Express 1:2 4K HDMI Splitter
• Power supply (5V DC 1A)
• User manual
