AC Unico AC-515T1/3-inch SonySuper

AC Unico AC-515T 1/3-inch Sony Super HAD CCD Box Camera — a compact security camera body with a 1/3-inch Sony Super HAD CCD sensor, 540 TV-line horizontal resolution, and C/CS lens mount compatibility. Lens not included.

The AC Unico AC-515T accepts a wide range of C/CS mount lenses (sold separately) and outputs a standard BNC video signal, compatible with both PAL and NTSC systems. Back light compensation and electronic shutter can be switched on or off as required. Backed by a 1-year warranty.

Key features

• 1/3-inch Sony Super HAD CCD image sensor
• 540 TV-line horizontal resolution
• 0.5 Lux minimum illumination (F1.2)
• C/CS lens mount — compatible with various lenses (lens not included)
• PAL/NTSC compatible
• BNC video output

Specifications

• Model: AC-515T
• Image Sensor: 1/3-inch Sony Super HAD CCD
• Effective Pixels: PAL: 792(H)×698(V) / NTSC: 768(H)×494(V)
• Sensing Area: 4.8 mm × 3.6 mm
• Horizontal Resolution: 540 TV lines
• Min. Illumination: 0.5 Lux (F1.2)
• Signal System: PAL/NTSC
• Lens Mount: C/CS mount (optional)
• S/N Ratio: >52 dB (AGC off)
• Video Output: 1.0 Vp-p, 75Ω BNC
• Power: 12 V DC / 500 mA
• Power Consumption: <2.0 W
• Dimensions: 90 × 58 × 60 mm
• Warranty: 1 year
