AC UnicoAC-611CS/3 420TVLColour

AC Unico AC-611CS/3 — analogue colour dome camera with 1/3-inch Sharp CCD sensor, 420 TVL horizontal resolution, 3.6mm fixed lens, and DC 12V power for indoor CCTV installations.

The AC-611CS/3 is a standard-definition analogue dome camera designed for legacy CCTV systems. The 1/3-inch Sharp CCD sensor delivers 420 TV lines of horizontal resolution with a minimum illumination of 1 Lux at F1.2, providing usable colour imagery in moderately lit environments. The 3.6mm fixed lens provides a wide-angle view suited to small retail areas, offices, and reception zones. BNC video output connects directly to analogue DVRs and multiplexers. The compact 76×60mm form factor allows discreet ceiling or wall mounting.

Key features

• 1/3-inch Sharp CCD colour sensor
• 420 TVL horizontal resolution
• 3.6mm wide-angle fixed lens
• Minimum illumination 1 Lux / F1.2
• BNC video output, PAL/NTSC selectable
• Compact dome form factor (76×60mm)

Specifications

• Model: AC-611CS/3
• Image sensor: 1/3″ Sharp CCD
• Effective pixels: PAL: 500(H)×582(V); NTSC: 510(H)×492(V)
• Horizontal resolution: 420 TV lines
• Lens: 3.6mm fixed
• Min. illumination: 1.0 Lux / F1.2
• S/N ratio: >48dB (AGC off)
• Video output: 1.0Vp-p, 75Ω (BNC)
• Power: DC 12V / 500mA, max 2.8W
• Dimensions: 76mm × 60mm
• Warranty: 1 year
