Arktek H610LGA1700 Micro-ATXMotherboard

Arktek H610 LGA1700 — Intel H610 chipset Micro-ATX motherboard supporting 12th/13th Gen Core processors with dual-channel DDR4 and three integrated graphics outputs.

The AK-H610M-EG offers a cost-effective platform for Intel LGA1700 builds, supporting Core i9, i7, i5, and i3 processors. Two DDR4 DIMM slots support up to 64GB at 2800MHz, four SATA 3.0 ports and an M.2 slot cover storage needs, and Realtek Gigabit LAN with Wake-on-LAN provides reliable network connectivity. Multiple video outputs — DisplayPort, VGA, and HDMI — cover most display configurations.

Key features

• Intel H610 chipset, LGA1700 socket
• Supports 12th/13th Gen Core i9/i7/i5/i3 processors
• Dual-channel DDR4 up to 2800MHz (2 DIMM slots)
• Integrated Intel HD Graphics with DisplayPort, VGA, and HDMI outputs
• Realtek 8111H Gigabit LAN with Wake-on-LAN and PXE
• 6-channel HD audio onboard
• 4 × SATA 3.0 + M.2 (SATA) + M.2 (Wi-Fi/Bluetooth)

Specifications

• Model: AK-H610M-EG
• Chipset: Intel H610
• Socket: LGA1700
• Form factor: Micro-ATX (22 × 18cm)
• Memory: 2 × DDR4 DIMM, up to 2800MHz, max 64GB
• Storage: 4 × SATA 3.0, 1 × M.2 (SATA), 1 × M.2 (Wi-Fi/BT)
• Display output: 1 × DisplayPort, 1 × VGA, 1 × HDMI
• LAN: Realtek 8111H Gigabit
• USB (rear): 2 × USB 3.0, 2 × USB 2.0
• Audio: 6-channel HD (3 × audio jack rear)
• OS support: Windows 7 / 8 / 8.1 / 10 (64-bit)
• Warranty: 3 years
