Epson BusinessProjector, 5200Ansi

Epson EB-L520U - WUXGA Laser Display

The Epson EB-L520U is a high-brightness WUXGA laser projector delivering vibrant, scalable displays up to 500 inches. Ideal for commercial and installation use, it supports 4K input, edge blending, and advanced geometric correction for seamless large-format visuals.

Key Features

• 5,200 lumens high brightness for clear, vivid images
• WUXGA resolution with Full HD support and 4K input compatibility
• Edge blending and geometric correction for seamless multi-projector setups
• Split-screen function allowing two or four images from different sources
• Wireless collaboration via Epson’s ELPWP10 wireless presentation system (optional)
• HDBaseT connectivity for high-quality content distribution
• Long-lasting laser light source with up to 30,000 hours in eco mode
• Reliable, low-maintenance design with a 3-year warranty
• Supports social distancing with scalable display sizes for any audience

Specifications

• Projection System: 3LCD Technology, RGB liquid crystal shutter
• LCD Panel: 0.67 inch with C2 Fine
• Colour Light Output: 5,200 lumens (3,640 lumens economy) - IDMS15.4 compliant
• White Light Output: 5,200 lumens (3,640 lumens economy) - ISO 21118:2020 compliant
• Resolution: WUXGA (1920 x 1200)
• High Definition: Full HD supported
• Aspect Ratio: 16:10
• Contrast Ratio: 5,000,000 : 1
• Light Source: Laser
• Laser Light Source Durability: 20,000 hours (High), 30,000 hours (Eco)
• Keystone Correction: Manual vertical ±30°, manual horizontal ±30°
• Colour Video Processing: 10 bits
• 2D Vertical Refresh Rate: 192 Hz - 240 Hz
• Colour Reproduction: Up to 1.07 billion colours
• Throw Ratio: 1.35 - 2.20:1
• Zoom: Manual, factor 1 - 1.6
• Projection Lens Zoom Ratio: 1.35 - 2.2 : 1
• Lens: Optical
• Screen Size: 50 inches - 500 inches
• Projection Lens F Number: 1.5 - 1.7
• Projection Lens Focal Length: 20 mm - 31.8 mm
• Projection Lens Focus: Manual
• Offset: 27 : 1
• Connectivity Interfaces: RS-232C, Wireless LAN a/n (5GHz) (optional), VGA in (2x), VGA out, HDMI in (2x), HDBaseT, Miracast (optional), Jack plug out, Jack plug in (2x), USB 2.0-A, USB 2.0, Ethernet (100 Base-TX / 10 Base-T)
• Epson iProjection App: Supports Ad-Hoc / Infrastructure modes
• Security: Kensington lock, padlock, security cable hole, wireless LAN unit lock
• 2D Colour Modes: Dynamic, Cinema, Presentation, sRGB, DICOM SIM
• Video Colour Modes: Cinema, Dynamic, Presentation, sRGB, DICOM SIM
• Other Features: 21:9 aspect ratio support, A/V mute, arc correction, built-in speaker, CEC compatible, easy OSD pre-setting, edge blending, long light source life, PC free operation, quick corner, screen share, source function, ultra-wide display (16:6), iProjection App

What's in the Box?

• HDMI cable
• Power cable
• Remote control with batteries
• User guide
• Warranty documents
