Lab Gruppen CA 60160 Watt CommercialAmplifier

Lab Gruppen CA601 - 60 Watt Commercial Amplifier with Energy Star Certification

The Lab Gruppen CA601 is a compact, efficient 60-watt per channel Class D amplifier designed for commercial audio applications. Ideal for small to medium installations such as retail spaces, educational facilities, bars, restaurants, and conference rooms, it delivers high-quality sound with low power consumption and minimal heat output.

Key Features

• 60 watts per channel at 4 ohms or 70V/100V for distributed audio systems
• Class D amplifier design for energy efficiency and reliability
• Convection cooling for silent operation without fans
• Flexible input/output connections using Euroblock terminals for easy installation
• Protection circuitry against overloading, overheating, and short circuits
• Energy Star certified with direct drive constant power technology to reduce power consumption
• Automatic power on/off based on input signal to save energy
• Simple controls including front panel power button, master volume, and tool-accessible bass and treble adjustments
• Expandable remote control options via RJ45 for wall and tabletop controllers
• System scalability with single and dual zone models for flexible installations
• Easy installation with rubber feet, optional rack mounting, and wall or under-shelf mounting brackets included

Product Details

The CA601 supports both low impedance (4/8 Ω) and high impedance (70/100 V) loudspeaker configurations, offering extreme flexibility. It features a high-pass filter to protect transformer-enabled loudspeakers and maintain sound integrity. Input options include balanced 3-pin Euroblock and unbalanced RCA (summed to mono), with loudspeaker output via a 2-pin Euroblock connector. The amplifier’s intuitive dipswitches allow easy output configuration.

Its automatic power management reduces electricity costs by entering sleep mode after 20 minutes without input signal and instantly powering on when audio is detected. The direct drive constant power technology lowers mains power requirements, often allowing use of existing electrical infrastructure, reducing installation and operational expenses while protecting the environment.

Specifications

• Power Output: 60 W per channel at 4 Ω
• Amplifier Class: Class D
• Cooling: Convection (fanless)
• Input Connections: 3-pin Euroblock (balanced), RCA (unbalanced, summed to mono)
• Output Connections: 2-pin Euroblock
• Output Configuration: 4 Ω, 8 Ω, 70 V, 100 V selectable via dipswitches
• Protection: Overload, overheat, short circuit
• Remote Control: RJ45 for CRC-V Series wall controllers and LAB.LEVEL tabletop controller
• Power Management: Automatic power on/off with sleep mode
• Mounting: Rubber feet, optional rack mount, wall or under-shelf brackets included
• Certification: Energy Star

What's in the Box

• Lab Gruppen CA601 Amplifier
• Rack mounting brackets
• Wall/under-shelf mounting brackets
• Rubber feet
