Lab Gruppen CA 6022 x 60 WattCommercial

Lab Gruppen CA 602 - 2 x 60 Watt Commercial Amplifier with Energy Star Certification

The Lab Gruppen CA602 is a compact, energy-efficient two-channel power amplifier delivering 60 watts per channel at 4 ohms. Ideal for commercial and industrial audio applications, it suits smaller sound systems in venues such as retail stores, restaurants, educational facilities, and conference rooms. Featuring Class D amplifier technology, the CA602 ensures reliable performance while minimising power consumption and heat output.

Key Features

• 60 watts per channel at 4 ohms, with support for 70V/100V distributed systems
• Class D amplification for energy efficiency and low heat generation
• Euroblock connectors for easy installation and integration with professional audio systems
• Convection cooling for silent, fanless operation in noise-sensitive environments
• Built-in protection circuits against overloads, overheating, and short circuits
• Energy Star certified for reduced power consumption and operational savings
• Automatic power on/off based on input signal to reduce energy use
• Flexible output configuration with dipswitches for 100 V, 70 V, 8 Ω, or 4 Ω operation
• Expandable remote control options via RJ45 for wall or tabletop controllers
• Easy installation with rubber feet, optional rack mounting, and wall/table mounting brackets
• Sublimely simple controls including front panel power and master volume knobs, plus tool-accessible bass and treble adjustments

Overview

The CA602 provides two independent audio channels, allowing amplification of separate zones. It supports both low-impedance (4/8 ohm) and high-impedance (70/100 V) loudspeaker configurations, offering extreme flexibility. Designed for ease of use, it is suitable for bars, restaurants, retail destinations, hotels, corporate offices, educational institutions, and other venues requiring background music or public address systems.

Its direct drive constant power technology not only enhances audio performance and reliability but also reduces mains power consumption, enabling installation using existing mains infrastructure. This results in significant installation and operational savings while protecting the environment.

Specifications

• Power Output: 2 x 60 watts at 4 ohms
• Amplifier Class: Class D
• Speaker Load: Supports 4 Ω, 8 Ω, 70 V, and 100 V configurations
• Cooling: Convection (fanless)
• Input Connectors: 3-pin Euroblock (balanced), RCA (unbalanced, summed to mono)
• Output Connectors: 4-pin Euroblock
• Remote Control: RJ45 for CRC-V Series wall controllers and LAB.LEVEL tabletop controller
• Protection: Overload, overheating, and short circuit safeguards
• Energy Certification: Energy Star

What's in the Box

• Lab Gruppen CA602 Amplifier
• Rack mounting hardware (brackets)
• Rubber feet
• Wall/table mounting brackets
