PSS M Series 2KVATrue Online UPSRack/Tower

PSS M Series 2KVA True Online UPS — a rack/tower convertible double-conversion UPS delivering 2KVA/1800W pure sine wave output for servers, workstations, and critical IT infrastructure.

Like its 3KVA sibling, the M2RT uses true online double-conversion technology to provide a continuously regenerated pure sine wave output, protecting equipment from surges, sags, and mains noise. Four hot-swappable 12V/9Ah batteries at 48VDC provide approximately 10 minutes of internal runtime, extensible to 4 hours with external battery banks. An optional SNMP/dry contact card enables remote monitoring and remote emergency shutdown (EPO). The LCD control panel shows load, voltage, and battery status at a glance, and ECO mode achieves up to 94% efficiency under normal grid conditions.

Key features

• True online double-conversion — pure sine wave on mains and battery
• 2KVA / 1800W capacity, 0.9 power factor
• Rack/tower convertible chassis
• Hot-swappable battery pack — 4 × 12V/9Ah (48VDC)
• Up to 4 hours runtime with extended battery banks
• Full LCD digital display with DSP control
• Optional SNMP/dry contact intelligent management card
• ECO mode efficiency up to 94%

Specifications

• Model: M2RT
• Capacity: 2KVA / 1800W
• Power factor: 0.9
• Input/output voltage: 230V single phase with ground
• Voltage range (full load): 200–290V AC
• Frequency range: 40–70 Hz
• Efficiency (ECO mode): Up to 94%
• Battery: 4 × 12V/9Ah lead acid; 48VDC; hot-swappable
• Recharge time: 5 hours
• Management: Optional SNMP/dry contact card; EPO remote shutdown
• Alarms: Audible: battery mode, low battery, overload, fault
• Operating environment: 0–40°C, 0–90% RH (non-condensing)
• Dimensions: 440 × 560 × 86.5 mm
• Weight: 28.5 kg (net) / 31 kg (gross)
• Warranty: 12 months
