( 01 / 01 )Yamaha MusicCastVINYL 500(TT-N503)
The Yamaha MusicCast VINYL 500 is a premium WiFi turntable that combines classic vinyl playback with modern wireless streaming technology. Enjoy your record collection anywhere in your home with seamless multi-room audio and superior Yamaha sound quality.
Key Features
- Belt-drive turntable (TT-N503) with a static-balance straight tonearm and aluminium die-cast 30 cm platter; 33 1/3 and 45 rpm
- Built-in phono equaliser: switchable PHONO OUT or LINE OUT (RCA)
- MusicCast network turntable: Ethernet, Wi-Fi (2.4 / 5 GHz) and AirPlay 2 (iOS 11.4 or later)
- Bluetooth 4.2 sink (A2DP / AVRCP, SBC / AAC) so a phone or tablet can play to the unit; 10 m range without interference
- MusicCast CONTROLLER app for internet radio, PC/NAS files and streaming services (availability varies)
- Supplied MM cartridge; AC adaptor 100-240 V, 12 V 1 A
Vinyl playback
The MusicCast VINYL 500 (TT-N503) is a belt-drive, DC-motor turntable. Yamaha specifies wow and flutter of 0.2 %, rotation-speed variation of ±2 %, and a 30 cm aluminium die-cast platter. The static-balance straight tonearm has an effective length of 223.5 mm and 19 mm overhang. An MM cartridge is attached. Set the audio-output switch to LINE OUT to use the built-in phono equaliser, or to PHONO OUT to feed an external phono stage.
MusicCast, network and Bluetooth
Register the unit with MusicCast CONTROLLER to play records, internet radio, network files and Bluetooth audio, and to share playback with other MusicCast devices. Wired Ethernet and dual-band Wi-Fi are provided. AirPlay 2 requires iOS 11.4 or later. Bluetooth on this model is a sink: the unit plays audio sent from a Bluetooth source device (it is not specified as a Bluetooth transmitter to headphones).
Specifications
Figures below are from the Yamaha UK MusicCast VINYL 500 spec page and the Yamaha TT-N503 owner's manual Specifications (English, printed pages 45-46) plus Supported devices and file formats (printed page 43). TT-S303 values are not used.
Turntable (platter)
Source: Yamaha UK MusicCast VINYL 500 specs page (Turntable) and TT-N503 owner's manual, Specifications, Platter section, printed p. 45.
| Model | MusicCast VINYL 500 (TT-N503) |
|---|---|
| Drive method | Belt drive |
| Motor | DC motor |
| Rotation speed | 33 1/3 rpm, 45 rpm |
| Rotation speed variation | ±2 % |
| Wow and flutter | 0.2 % |
| Platter | Aluminium die-cast, diameter 30 cm |
| Output level (with RIAA EQ) | 450 mV (−7 dBV, 1 kHz, 3.54 cm/s) |
| Output level (without RIAA EQ) | 2.5 mV ± 3 dBV (1 kHz, 3.54 cm/s) |
| Signal to noise ratio (phono) | 67 dB or higher (A-weighted, 20 kHz LPF) |
Tonearm and cartridge
Source: Yamaha UK specs page (Tonearm / Attached Cartridge) and TT-N503 owner's manual, Specifications, Tone arm and Cartridge sections, printed p. 45.
| Tonearm | Static balance straight tonearm |
|---|---|
| Effective arm length | 223.5 mm |
| Overhang | 19 mm |
| Stylus pressure adjustment range | 0-4 g |
| Acceptable cartridge weight | 15.5-19 g (including headshell) |
| Cartridge type | MM |
| Cartridge output voltage | 2.5 mV (1 kHz, 3.54 cm/s) |
| Stylus pressure | 3.5 ± 0.5 g |
| Cartridge weight | 5.0 ± 0.3 g |
| Cartridge height | 17.0 ± 0.7 mm |
| Headshell weight | 10 g (including screws, nuts and wires) |
Analogue outputs (PHONO / LINE)
Source: Yamaha UK specs page (Audio Specifications, Output Terminal) and TT-N503 owner's manual, Input/output terminals and Audio section (PHONO), printed pp. 45-46.
| Output terminals | RCA × 2 (PHONO, LINE) |
|---|---|
| NETWORK (wired) | × 1 (100Base-TX / 10Base-T) |
| PHONO OUT | 2.5 mV ± 3 dBV (1 kHz, 3.54 cm/s); cartridge signal, no built-in EQ |
| LINE OUT (phono EQ on) | 450 mV (−7 dBV, 1 kHz, 3.54 cm/s) |
| Phono S/N | 67 dB or higher (A-weighted, 20 kHz LPF) |
Network, Wi-Fi and Bluetooth
Source: Yamaha UK specs page (Network Section / Bluetooth Section). Wireless standards, WPS/security, Bluetooth Class 2 and sink function: TT-N503 owner's manual, printed pp. 45-46. AirPlay 2: owner's manual, printed p. 43 (UK spec page lists AirPlay: Yes).
| Ethernet | Yes |
|---|---|
| Wi-Fi | Yes (2.4 / 5 GHz) |
| Wireless network standards | IEEE 802.11 a/b/g/n/ac (20 MHz channel bandwidth only) |
| WPS | PIN method |
| Wi-Fi security | WEP; WPA2-PSK (AES); mixed mode |
| AirPlay | AirPlay 2 (iOS 11.4 or later) |
| Bluetooth version / profiles | Ver. 4.2 / A2DP, AVRCP |
| Bluetooth codecs | SBC, AAC |
| Bluetooth role | Sink (source device such as a smartphone/tablet plays to this unit) |
| Bluetooth class | Class 2 |
| Maximum communication range | 10 m without interference |
Audio specifications (network / Bluetooth playback)
Source: Yamaha UK specs page (Audio Specifications) and TT-N503 owner's manual, Audio section (Network, Bluetooth), printed p. 46.
| Output level | 2.0 ± 0.3 V (1 kHz, 0 dB, Fs 44.1 kHz) |
|---|---|
| Signal to noise ratio | 110 dB or higher (IHF-A network, infinity zero, Fs 44.1 kHz) |
| Dynamic range | 100 dB or higher (1 kHz, −60 dB, Fs 44.1 kHz) |
| Harmonic distortion | 0.003 % or lower (1 kHz, 0 dB, Fs 44.1 kHz) |
| Frequency response (Fs 44.1 kHz) | 2 Hz - 20 kHz (+0 / −3 dB) |
| Frequency response (Fs 48 kHz) | 2 Hz - 24 kHz (+0 / −3 dB) |
| Frequency response (Fs 96 kHz) | 2 Hz - 48 kHz (+0 / −3 dB) |
| Frequency response (Fs 192 kHz) | 2 Hz - 96 kHz (+0 / −6 dB) |
PC / NAS file formats
Source: Yamaha UK specs page (Network Section, File Format) for the published maxima; detailed sampling/bitrate/gapless rows from the TT-N503 owner's manual, printed p. 43. WAV is linear PCM only. DRM-encoded content cannot be played.
| UK spec maxima | MP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit; ALAC: up to 96 kHz / 24-bit; FLAC / WAV / AIFF: up to 192 kHz / 24-bit; DSD: up to 11.2 MHz |
|---|---|
| WAV | 32 / 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz; 16/24-bit; 2 ch; gapless |
| MP3 | 32 / 44.1 / 48 kHz; 8-320 kbps; 2 ch |
| WMA | 32 / 44.1 / 48 kHz; 8-320 kbps; 2 ch |
| MPEG-4 AAC | 32 / 44.1 / 48 kHz; 8-320 kbps; 2 ch |
| FLAC | 32 / 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz; 16/24-bit; 2 ch; gapless |
| ALAC | 32 / 44.1 / 48 / 88.2 / 96 kHz; 16/24-bit; 2 ch; gapless |
| AIFF | 32 / 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz; 16/24-bit; 2 ch; gapless |
| DSD | 2.8 / 5.6 / 11.2 MHz; 1-bit; 2 ch |
General
Source: Yamaha UK specs page (General) for consumption, eco-standby, network-standby, dimensions and weight. AC adaptor ratings: TT-N503 owner's manual, printed p. 46. Network-standby wattage on the UK spec page (1.4 / 1.8 / 1.6 W) is used here; the owner's manual prints 2.0 W for those same modes and is not mixed in.
| AC adaptor input | AC 100-240 V, 50/60 Hz |
|---|---|
| AC adaptor output | 12 V, 1 A |
| Power consumption | 6 W |
| Eco-standby (reference) | 0.3 W |
| Network standby ON, Bluetooth standby OFF, wired | 1.4 W |
| Network standby ON, Bluetooth standby ON/OFF, Wi-Fi | 1.8 W |
| Network standby ON, Bluetooth standby ON, wired | 1.6 W |
| Dimensions (W × H × D) | 450 × 136 × 368 mm (including legs and protrusions) |
| Weight | 5.7 kg |
